Yamaha MX360 - Engine Switch

ENGINE SWITCH AND OIL WARNING UNIT
3-32
1
2
3
4
5
6
7
8
9
10
ENGINE
ENGINE SWITCH
Order Job/Parts to remove Q’ty Remarks
Removing the engine switch Remove the parts in the order listed.
Fuel tank
Refer to “FUEL TANK (Equipped models)” on
page 3-5.
Fuel tank stay
Refer to “FUEL TANK (Equipped models)” on
page 3-5.
1 Engine switch 1
4.5 N・m (0.45 kgf・m, 3.3 lb・ft)
1
