Yamaha MX360 - ENGINE SWITCH and OIL WARNING UNIT (no Oil Level Switch)

WIRE ROUTING DIAGRAM
7-22
1
2
3
4
5
6
7
8
9
10
SPECIFICATIONS
ENGINE SWITCH AND OIL WARNING UNIT (No oil level switch)
Color code
1. Engine switch
A. Attach the projection of the engine switch to the hole of the bracket.
B Black B/W Black/White
