WIRE ROUTING DIAGRAM
7-21
1
2
3
4
5
6
7
8
9
10
SPECIFICATIONS
Color code
1. Engine switch 3. Wire harness protector
2. Engine switch lead (ground) 4. Clamp
A. Unused yellow and black/white lead wires are stored in the wire harness protector and fixed with a
clamp together with other lead wires.
B. Clamp the connector part.
C. The lead is black and the protector is gray.
B Black Y Yellow
L Blue B/W Black/White
R Red
