Yamaha MX360 - Top

DIMENSIONS
1-4
1
2
3
4
5
6
7
8
9
10
GENERAL INFORMATION
*1: UNF: Unified fine thread (Unit: in)
A: 7HCC (MZ360LHIDE, P.T.O. type L (Taper · millimeter))
B: 7HCB, 7HSB (MX360KA6D0 except for KOR, MZ400KH2P6, P.T.O. type K (Taper · inch))
C: 7HCB (MX360KA6D0 for KOR, P.T.O. type K (Taper · inch))
D: 7HC2 (MX360BA6A0, P.T.O. type B (Straight · millimeter))
E: 7HC3 (MX360C46A5, P.T.O. type C (Straight · millimeter))
F: 7HCJ (MX360AA6A0, MX360AA6A5, MX360AA6A6, P.T.O. type A (Straight · inch))
TOP
mm (in)
6.31H10
0
+0.058
21.8
-0.1
0
4.5
5
72.2
28
60.3
88.5
25.4h7
-0.021
0
110H8
+0.054
0
146.08h7
-0.040
0
3/8 -24UNF-2B
444.6 (17.5)
162.7 (6.41) 281.9 (11.1)
277.8 (10.94)
