PERIODIC MAINTENANCE
2-13
1
2
3
4
5
6
7
8
9
10
PERIODIC CHECKS AND ADJUSTMENTS
3.
Pull the recoil starter slowly, and then set the piston at
TDC (top-dead-center) on the compression stroke.
TIP
Check the piston position by inserting a screw driver into
the spark plug hole.
4.
Measure:
• Valve clearance
(Between the rocker arm and valve stem end)
Out of specification  Adjust.
TIP
Valve clearance must be measured when the engine has
cooled down enough to be touched.
Thickness gauge:
90890-03268
Feeler gauge set:
YU-26900-9
Valve clearance (cold):
Intake: 0.05–0.09 mm (0.0020–0.0035 in)
Exhaust: 0.05–0.09 mm (0.0020–0.0035 in)
