YASKAWA FS100 - 11.4.2 LED Indicator During the Start-up Process

11 LED Indicator on Each Circuit Board
FS100 11.4 7 SEG-LED Indicator on SERVO Control Board (IFM)
11-9
11.4.2 LED Indicator During the Start-up Process
LED Status Meaning
Power supply is turned ON
Starts up boot program
Starts up boot system
(
Completes initialization )
Completes the preparation for receiving
the system program
Starts up the system program has
(
Starts up each hardware initialization )
Starts up the SERVO system
(Starts up each SERVO part
initialization)
Starts up pre-online processes
(LNK2 blinks at 0.3 sec intervals)
FS100 setup competed
(SERVO ON enabled)
(LNK2 blinks at 1 sec intervals)
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
OFF
OFF
OFF
OFFOFF
RDY
CN
LNK1
ERR
CMERR
LNK2
OFF
OFF
OFF
OFF
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
OFF
OFF
OFF
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
ON
OFF
OFF
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
ON
ON
OFF
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
ON
ON
ON
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
OFF
OFF
RDY
CN
LNK1
ERR
CMERR
LNK2
ON
OFF
OFF
