3 Maintenance and Inspections
FS100 3.2 Cooling Fan Inspections
3-3
3.2 Cooling Fan Inspections
Inspect the cooling fans as required. A defective fan can cause the FS100
to malfunction because of excessive high temperatures inside.
The interior circulation fan and cooling fan normally operate while the
power is turned ON. Check if the fans are operating correctly by visual
inspection and by feeling air moving into the air inlet and from the outlet.
Air intake
Air intake Air intake
Air outlet
Air outlet
Air outlet
Air outlet
Air outlet
(Backside View)
Cooling fan installing direction
(Top View)
Cooling wind direction
