YASKAWA FS100 - Calibrating Operation; Registering All Axes at One Time

7 Operations After Replacing Parts
FS100 7.1 Home Position Calibration
7-4
7.1.2 Calibrating Operation
7.1.2.1 Registering All Axes at One Time
1. Select {ROBOT} under the main menu.
2. Select {HOME POSITION}.
– The HOME POSITIONING window appears.
3. Select {DISPLAY} under the menu,
or select "PAGE" to display the selection window for the control group,
or press page key .
– The pull-down menu appears.
4. Select the desired control group.
