8
System Diag
nosis
FS100
8.8
Current Position
8-24
8.8
Current Position
8.8.1
Current Position Window
1.
Select {ROBOT
} under the main menu.
2.
Select {CURRENT POSITI
ON} under the sub me
nu.
–
The CURRENT POSITION window appears.
3.
Select the typ
es of coordinates to be displayed.
–
The pull-down
menu appe
ars.
4.
Select th
e desired coordinate system.
–
The type of coordinates being displayed is change
d.
