6 DCP Interface
20 YASKAWA TOEPC710616134G AC Drive L1000A Technical Manual Addendum
The checksum is the result of an XOR operation across all 5 data bytes.
Definition of Messages
The following two tables show the valid messages of DCP3 and DCP4 Command mode and the meaning of the
process information.
Table 6.1 Nomenclature
Setting Meaning
0 bit is cleared
1 bit is set
x any
Message Types in DCP3 Mode
Message Type
Command Mode Bits
7 6 5 4 3 2 1 0
Process Data
Communication
Data
Checksum
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Idle Mode x 0 x x 0 0 0 0 any any 0 - 255 0 - 255 0 - 255
Stop Mode x 0 x x 0 0 0 1 any any 0 - 255 0 - 255 0 - 255
Re-leveling Mode x 0 x x 0 0 1 1 any any 0 - 255 0 - 255 0 - 255
Deceleration Mode x 0 x x 0 1 0 1 any any 0 - 255 0 - 255 0 - 255
Travel Mode x 0 x x 0 1 1 1 any any 0 - 255 0 - 255 0 - 255
Speed Mode x 0 x x 1 0 0 1 Speed Speed 0 - 255 0 - 255 0 - 255
Speed Mode after a
Fast Start
x 0 x x 1 1 1 1 Speed Speed 0 - 255 0 - 255 0 - 255
Message Types in DCP4 Mode
Message Type
Command Mode Bits
7 6 5 4 3 2 1 0
Process Data
Communication
Data
Checksum
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Idle Mode x 0 x x 0 0 0 0 any any 0 - 255 0 - 255 0 - 255
Stop Mode x 0 x x 0 0 0 1 any any 0 - 255 0 - 255 0 - 255
Re-leveling Mode x 0 x x 0 0 1 1 any any 0 - 255 0 - 255 0 - 255
Remaining Distance
Mode
*1
x 0 x x 0 1 0 1
Remaining Distance
MSB
Remaining Distance
LSB
0 - 255 0 - 255 0 - 255
Deceleration Mode x 0 x x 0 1 0 1 any any 0 - 255 0 - 255 0 - 255
Travel Mode x 0 x x 0 1 1 1 any any 0 - 255 0 - 255 0 - 255
Speed Mode x 0 x x 1 0 0 1 Speed Speed 0 - 255 0 - 255 0 - 255
Speed Mode after a
Fast Start
x 0 x x 1 1 1 1 Speed Speed 0 - 255 0 - 255 0 - 255
*1 The next message after a Speed Mode message will decide how a "x 0 x x 0 1 0 1" message is processed:
If, after a Speed Mode change, a Travel Mode message follows, all occurrences of "x 0 x x 0 1 0 1" messages are processed as
Deceleration Mode messages.
If, after a Speed Mode message, a "x 0 x x 0 1 0 1" message follows, this and all other messages are processed as Remaining
Distance Mode messages.
Speed Mode
DCP speeds correspond to parameters listed below. Speeds are transferred in bytes 2 and 3 (data bytes) once
before a start of travel.
Speed Mode Bits DCP Name of Speed Mode
L1000A Standard Speed
Designation
Related L1000A Parameter L1000A DCP Designation
G0 V0 Crawl d1-26 V0 Speed
G1 VN Re-leveling d1-23 VN Speed
G2 VF - - VF Speed
G3 V1 Intermediate 3 d1-04 V1 Speed
