6 DCP Interface
62 YASKAWA TOEPC710616134G AC Drive L1000A Technical Manual Addendum
■ Added Standard Parameter Dependencies (Defaults)
H5-13 = x 0 1 3 4 5 3, 4 0, 1, 5
Parameter Default Value Parameter Texts
C1-01 3.00 s 1.50 s 3.00 s - -
C1-02 3.00 s 1.50 s 3.00 s - -
d1-01 0.00 % 100.00 % 0.00 % V4 Speed Reference 1
d1-02 0.00 % 64.00 % 0.00 % V3 Speed Reference 2
d1-03 0.00 % 40.00 % 0.00 % V2 Speed Reference 3
d1-04 0.00 % V1 Speed Reference 4
d1-05 0.00 % V7 Speed Reference 5
d1-06 0.00 % V6 Speed Reference 6
d1-07 0.00 % V5 Speed Reference 7
d1-23 0.00 % 1.00 % 0.00 % VN Speed Releveling Speed
d1-24 50.00 % 25.00 % 50.00 % VI Speed Inspect Oper Spd
d1-26 8.00 % 4.00 % 8.00 % V0 Speed Leveling Speed
■ Changes of Standard Digital Input Multi-Functions (DIMF)
DIMF Availability by H5-13 Setting
H1-xx Setting
(Hex)
Function Name H5-13 = 0, 1 H5-13 = 3 [DCP3]
H5-13 = 4, 5 [DCP4,
CANopen-Lift]
3 ... 5 Multi-Step Speed Reference 1~3
Available
Not available
Not available
6 JOG Reference Selection
7 Accel/Decel time selection Available
16 Motor 2 Selection Not available
1A Accel/Decel Time Selection 2 Available
50 Nominal Speed
Not available
51 Intermediate Speed
52 Releveling Speed
53 Leveling Speed
54 Inspection Operation
57 High Speed Limit (Up)
58 High Speed Limit (Down)
5C Floor Sensor Available
When H5-13 ≥ 3, values and defaults of the parameters H1-03 to H1-07 are set to 0xF [not used].
■ Changes of Standard Digital Output Multi-Functions (DOMF)
DOMF Availability by H5-13 Setting
H2-xx Setting
(Hex)
Function Name H5-13 = 0, 1 H5-13 = 3, 4, 5
1C (11C) Motor 2 Selection Available Not available
DOMF Availability by S4-01 Setting
H2-xx Setting
(Hex)
Function Name S4-01 < 3 S4-01 = 3
55 (155) Light Load Direction Detection Status Available Not available
Note:
S4-01 is not shown when H5-13 = 4. In this case, the value for H5-13 is set to 3 internally.
