YASKAWA SGDA series User Manual

APPLICATIONS OF Σ-SERIES PRODUCTS
3.8.6 Extending an Encoder Cablecont.
158
b) 50-meter (164 ft.) Extension Cable:
Cut this cable 30 cm (0.98 ft.) or less from each end.
Be sure to connect
each wire correctly
(see the following
table).
• For both incremental and absolute encoders: DP8409179
Maximum 50 m (164 ft.)
3
