SERVO SELECTION AND DATA SHEETS
5.6.16 Encoder Signal Converter Unit
336
5.6.16 Encoder Signal Converter Unit
1) Unit to convert the encoder signal output from the line driver to an open collector output or
voltage pulse output.
Line Receiver Unit
Terminal Numbers
Input A Phase
Input B Phase
Input B
Phase
Input Z Phase
Input Z
Phase
Output A Phase
Output B Phase
Output Z Phase
Input A Phase
Dimensional Drawings
11 M3.5 x 7
Seams screws
51 max.
(2.01)
Holes 2 x
4.5 mm dia.
(Φ0.18)
33.5 max.
(1.32)
118 max.
(4.65)
(1.97)
(5.08)
(3.94) (0.75)
(3.15)
(1.39)
(0,16) 81max(3.19)
(0.31)
(0.20)
(0.16)
(0.16)
(1.39)
(1.57¦0.0079)
5
