5.3 Servopack Rating and Specifications
245
5.3.6 In-rush Current and Power Loss
Servopack SGDA- In-rush Current (Peak
V
alue)
A
Output Current
(Effective
V
alue)
Power Loss
W
V
alue)
A
(Effective
V
alue)
A
W
Supply Voltage 200V A3 (30W-0.04HP) 35 0.42 15
A5 (50W-0.07HP) 35 0.6 18
01 (100W-0.13HP) 35 0.87 20
02 (200W-0.27HP) 350 2.0 35
04 (400W-0.53HP) 35 2.6 45
08 (750W-1.01HP) 70 4.4 60
Supply Voltage 100V A3 (30W-0.04HP) 18 0.63 17
A5 (50W-0.07HP) 18 0.9 20
01 (100W-0.13HP) 18 2.2 30
02 (200W-0.27HP) 18 2.7 47
03 (300W-0.40HP) 35 3.7 70
5
