USING THE DIGITAL OPERATOR
This chapter describes the basic operation of the digital operator and the con-
venient features it offers.
All constant settings and motor operations are possible by simple, conve-
nient, operation.
Operate the digital operator as you read through this chapter.
4.1 Basic Operations 168.........................
4.1.1 Connecting the Digital Operator 168........................
4.1.2 Resetting Servo Alarms 169..............................
4.1.3 Basic Functions and Mode Selection 170....................
4.1.4 Operation in Status Display Mode 171......................
4.1.5 Operation in User Constant Setting Mode 174................
4.1.6 Operation in Monitor Mode 179...........................
4.2 Using the Functions 183.......................
4.2.1 Operation in Alarm Trace-back Mode 183...................
4.2.2 Operation Using the Digital Operator 186....................
4.2.3 Autotuning 189........................................
4.2.4 Reference Offset Automatic Adjustment 196.................
4.2.5 Speed Reference Offset Manual Adjustment Mode 199.........
4.2.6 Clearing Alarm Trace-back Data 202.......................
4.2.7 Checking Motor Type 203................................
4.2.8 Checking Software Version 204...........................
