YASKAWA SGDA series User Manual

USING THE DIGITAL OPERATOR
4.1.5 Operation in User Constant Setting Modecont.
176
For JUSP-OP03A
1) Press
MODE/SET
to select the user constant
setting mode.
2) Press the
UP
and
DOWN
keys to select the
user constant number to set.
3) Press
DATA
to display the current data for
the user constant selected at step 2.
4) Press the
UP
and
DOWN
keys to change the
data to the required value.
5) Press
DATA
to store the data .
6) Press
DATA
once more to display the user
constant number again.
7) Repeat steps 2 to 6 as often as required.
• Refer to Appendix D List of User Constant Settings
4
JUSP-OP03A
Setti
ng
Mod
e
Setting
Mode
MODE/SET
User Constant Number
Value changes rapidly
when key held down
The stored data flashes.
Data
User Constant
Numberaa
