YASKAWA SGDA series User Manual

5.2SGM Servomotor
219
Electrical Specifications of the Holding Brake
a) SGM Type (Rated Voltage: 90 VDC) Standard..
Motor Model Motor
Capacity
(W)
Holding Brake Specifications
Capacity
(W)
Holding
Torque
(kg-cm)
Coil
Resistance
Ω (at 20°C)
Rated
Current
A ( at 20°C)
SGM-A3jjjj
30 6 2.0 1350 0.067
SGM-A5jjjj
50 6 2.0 1350 0.067
SGM-01jjjj
100 6 3.5 1350 0.067
SGM-02jjjj
200 6.5 15 1246 0.072
SGM-04jjjj
400 6.5 15 1246 0.072
SGM-08jjjj
750 6 25 1350 0.067
b) SGM Type (Rated Voltage: 24 VDC) Non-standard..
Motor Model Motor
Capacity
(W)
Holding Brake Specifications
Capacity
(W)
Holding
Torque
(kg-cm)
Coil
Resistance
Ω (at 20°C)
Rated
Current
A (at 20°C)
SGM-A3jjjj
30 6 2.0 96 0.25
SGM-A5jjjj
50 6 2.0 96 0.25
SGM-01jjjj
100 6 3.5 96 0.25
SGM-02jjjj
200 6.5 15 89 0.27
SGM-04jjjj
400 6.5 15 89 0.27
SGM-08jjjj
750 6 25 96 0.25
