5.4Σ -Series Dimensional Drawings
271
Note 1) The detector uses an incremental encoder 2048 P/R.
2) Type “A” indicates 200 V specification, and type “B” indicates 100 V specification.
3) “02A(B)314”, “02A(B)316”, “03B314”,“03B316”,“04A314” and“04A316”, have a keyed
shaft. The keyway complies with JIS B 1301-1976 (precision). A straight key is supplied.
4) The quoted allowable radial load is the value at a position 25 mm (0.98 in.) from the mo-
tor mounting surface.
5) Conforms to “IP55” protective structure (except connector and output shaft faces).
