SERVO SELECTION AND DATA SHEETS
5.4.1 Servomotor Dimensional Drawings
286
3) “02A(B)W14B”, “02A(B)W16B”, “03BW14B”, “03BW16B”, 04AW14B”, and “04AW16B”
have a keyed shaft. The keyway complies with JIS B 1301-1976 (precision). A straight
key is supplied.
4) The quoted allowable radial load is the value at a position 25 mm (0.98 in.) from the mo-
tor mounting surface.
5) The electromagnetic brake is only to hold the load in position and cannot be used to stop
the motor.
6) Conforms to IP55 protective structure (except connector and output shaft faces).
5
cont.
To Next Page
