5.5 Selecting Peripheral Devices
297
Use circuit
breaker for 5 A
power supply
capacity.
Use circuit
breaker for 9 A
power supply
capacity.
Use circuit
breaker for 16 A
power supply
capacity.
Use circuit
breaker for 5 A
power supply
capacity.
Use circuit
breaker for 8 A
power supply
capacity.
Use circuit
breaker for 15 A
power supply
capacity.
Noise filterNoise filterNoise filterNoise filter
from (b)
3) Select 1CN connector for
reference input.
Connector only /
Terminal block unit /
One cable end without connector
Connector only Connector-to-terminal
conversion unit
One cable end
without connector
Cable with 1CN
connector and one
end without connector
DE9404859−1
DE9404859−2
Servopack power
supply 200 V/100 V?
200 V 100 V
Servopack capacity? Servopack capacity?
30 to 200W 400W 750W 30 to 100W 200W 300W
Noise filter
LF−205A LF−220 LF−205A LF−210 LF−220
to (c)
Connector-to-terminal
conversion unit
1CN connector
JUSP−TA36P
DP9420007
DE9404859−3
4) Select circuit breaker (MCCB)
and noise filter.
Noise filter
LF−210
1m
2m
3m
(3.3ft)
(6.6ft)
(9.8ft)
(0.04 to 0.27HP) (0.53HP) (1.01HP) (0.04 to 0.13HP) (0.27HP) (0.40HP)
5
