YASKAWA SGDA series User Manual

5.6Specifications and Dimensional Drawings of Peripheral Devices
327
• Case
For -52A0
Diagram of Assembled Connector (for reference)
(0.22)
(0.94)
(0.5)
Units: mm (inches)
Connect
or Type
Case
Type
A B C D E F
10136-
3000VE
10336-52
A0-008
32.2
(1.27)
43.5
(1.71)
18.0
(0.71)
17.0
(0.67)
14.0
(0.55)
37.6
(1.48)
2) The 1CN connector type is shown below.
Connector
T
Application
Connector Part List
Type
pp
Connector Case
Type Qty Type Qty
DP9420007 I/O connector
for 1CN
10136-3000V
E*
1 10336-52A0-
008*
1
* Manufactured by 3M.
