YASKAWA SGDA series User Manual

6.2Troubleshooting
351
Cause Remedy
A Servomotor wiring incorrect.
Check and correct wiring. (Check A-, B-,
Ch
l
2CN )
B Encoder wiring incorrect (disconnection,
shortcircuit, power supply, etc.)
g
(
,
,
C-phase pulses correct at 2CN.)
C Servopack adjustment incorrect Increase speed loop gain (Cn-04) and/or
position loop gain (Cn-1A).
D Servomotor overloaded Reduce load torque and inertia. Otherwise,
replace with larger capacity servomotor.
E Position reference pulse frequency too
high
• Decrease reference pulse frequency.
• Use smoothing function.
• Change electronic gear ratio.
F Circuit board (1PWB) defective. Replace Servopack.
Display and Outputs
Digital Operator
Di l
d
Alarm Output
g
p
Display and
Alarm
Name
Alarm Code Output
Alarm Output
Al
arm
N
ame
ALO1 ALO2 ALO3
p
A.40
Overvoltage
OFF OFF ON OFF
OFF: Output transistor is OFF
ON: Output transistor is ON
Status When Alarm Occurred
A
,D
During servomotor
operation
During motor
deceleration
During normal
operation
At power ON
B
,
C
,D
E
,
F
Cause Remedy
A Load inertia high and motor speed too high
• Change operating conditions.
• Use regenerative unit.
• If multiple units are used, connect all P, N
terminals in parallel.
B Load exceeds capacity of regenerative unit Change operating conditions.
C Servomotor speed too high Reduce motor speed.
D Servopack defective Replace Servopack.
E Input voltage too high Change input voltage to normal value.
F Circuit board (1PWB) defective. Replace Servopack.
