6 Adjustments
6.8.1 Switching Gain Settings
6-60
(5) Parameters for Automatic Gain Switching
(6) Related Monitor
Note: When using the tuning-less function, gain setting 1 is enabled.
Pn131
Gain Switching Time 1
Classification
Setting Range Setting Unit Factory Setting When Enabled
0 to 65535 1 ms 0 Immediately Tuning
Pn132
Gain Switching Time 2
Classification
Setting Range Setting Unit Factory Setting When Enabled
0 to 65535 1 ms 0 Immediately Tuning
Pn135
Gain Switching Waiting Time 1
Classification
Setting Range Setting Unit Factory Setting When Enabled
0 to 65535 1 ms 0 Immediately Tuning
Pn136
Gain Switching Waiting Time 2
Classification
Setting Range Setting Unit Factory Setting When Enabled
0 to 65535 1 ms 0 Immediately Tuning
Monitor No. (Un) Name Value Remarks
Un014 Effective gain monitor
1 For gain setting 1
2 For gain setting 2
Speed
Position
Speed
Position
Speed
Position
Speed
Position
Parameter
Analog
Monitor
Name Output Value Remarks
Pn006
Pn007
n.0B
Effective gain moni-
tor
1 V Gain setting 1 is enabled.
2 V Gain setting 2 is enabled.
