YASKAWA SGMPS - Input Signal Display Example

8 Monitor Modes (Un)
8.4.3 Input Signal Display Example
8-6
8.4.3 Input Signal Display Example
Input signals are displayed as shown below.
• When /S-ON signal is ON (Servo ON at L level)
• When /S-ON signal is OFF
• When P-OT signal operates (Operates at “H” level)
The bottom segment
of number 1 is lit.
76543218
The top segment of
number 1 is lit.
76543218
The top segment of
number 3 is lit.
76543218
