3 Wiring and Connection
3.7.2 Precautions on Connecting Noise Filter
3-44
Connect the noise filter ground wir
e directly to the ground pla
te.
Do not connect the noise filter ground wire to other ground wires.
If a noise filter is located inside a control p
anel, connect the no
ise filter ground wire and the groun
d
wires from other devices inside the control pane
l to
the ground pla
te for the c
o
ntrol panel first, then
ground these wires.
×
Shielded
ground wire
Noise
Filter
Noise
Filter
Box
Box
SERVOP
ACK
SERVOP
ACK
SER
VOP
ACK
SERVOP
ACK
Noise
Filter
Control Panel
Ground
Box
SERVOP
ACK
SERVOP
ACK
90
92
