Yealink T29G Administrator's Guide

Configuring Basic Features
119
The following table lists the logo file format, resolution for each phone model.
Phone Model
Logo File Format
Resolution
SIP-T42G/T41P
.dob
<=192*64 2 gray scale
SIP-T27P
.dob
<=240*120 2 gray scale
SIP-T23P/T23G/T21(P) E2
.dob
<=132*64 2 gray scale
Note
Procedure
The logo shown on the idle screen can be configured using the configuration files or
locally.
Configuration File
<y0000000000xx>.cfg
Configure the logo shown on the
idle screen and specify the
access URL of the custom logo
file.
Parameters:
phone_setting.lcd_logo.mode
lcd_logo.url
Local
Web User Interface
Configure the logo shown on the
idle screen.
Navigate to:
http://<phoneIPAddress>/servlet
?p=features-general&q=load
Details of Configuration Parameters:
Parameters
Permitted Values
Default
phone_setting.lcd_logo.mode
0, 1 or 2
0
Description:
Configures the logo mode of the LCD screen.
0-Disabled
1-System logo
2-Custom logo
Before uploading your custom logo to IP phones, ensure your logo file is correctly
formatted. For more information on customizing a logo file, refer to Yealink IP Phones
Auto Provisioning Guide.

Yealink T29G Specifications

General

VoIP Protocols	SIP
PoE Support	Yes (IEEE 802.3af)
Headset Port	RJ9
Bluetooth	No
Weight	1.04 kg
Display	4.3" color display with backlight, 480 x 272 pixels
Line Keys	10 line keys
Ethernet Ports	2 x 10/100/1000 Mbps
Audio Codecs	G.722, G.711, G.729, G.726, iLBC
USB Port	1 x USB 2.0
Expansion Module Support	Yes, supports up to 6 EXP20 expansion modules
EHS	Yes
Supported Protocols	SIP
Operating Temperature	-10~50°C
Humidity	10% to 95% (non-condensing)
