Yealink T29G Administrator's Guide

Configuring Security Features
507
3. (Optional.) Click Browse to locate the target directory from your local system in the
Target Directory field.
The tool uses the file folder “Encrypted” as the target directory by default.
4. (Optional.) Mark the desired radio box in the AES Model field.
If you mark the Manual radio box, you can enter an AES key in the AES KEY field or
click Re-Generate to generate an AES key in the AES KEY field. The configuration
file(s) will be encrypted using the AES key in the AES KEY field.
If you mark the Auto Generate radio box, the configuration file(s) will be encrypted
using random AES key. The AES keys of configuration files are different.
Note
5. Click Encrypt to encrypt the configuration file(s).
6. Click OK.
The target directory will be automatically opened. You can find the encrypted CFG
file(s), encrypted key file(s) and an Aeskey.txt file storing plaintext AES key(s).
AES keys must be 16 characters and the supported characters contain: 0 ~ 9, A ~ Z, a ~
z and the following special characters are also supported: # $ % * + , - . : = ? @ [ ] ^ _ { }
~.

Yealink T29G Specifications

General

VoIP Protocols	SIP
PoE Support	Yes (IEEE 802.3af)
Headset Port	RJ9
Bluetooth	No
Weight	1.04 kg
Display	4.3" color display with backlight, 480 x 272 pixels
Line Keys	10 line keys
Ethernet Ports	2 x 10/100/1000 Mbps
Audio Codecs	G.722, G.711, G.729, G.726, iLBC
USB Port	1 x USB 2.0
Expansion Module Support	Yes, supports up to 6 EXP20 expansion modules
EHS	Yes
Supported Protocols	SIP
Operating Temperature	-10~50°C
Humidity	10% to 95% (non-condensing)
