YOKOGAWA CA150 User Manual

Communication Function
8-11
IM CA150E
1
2
3
4
5
6
7
8
9
10
11
12
App
OS Normal SettingOutputs the setting information (conditions)
○ × Command = OS<Delimiter> → Return = Measure a<Delimiter>
Function b<Delimiter>
Range c<Delimiter>
Source d<Delimiter>
Function e<Delimiter>
Range f<Delimiter>
Data g<Delimiter>
24 V Output h<Delimiter>
Light i<Delimiter>
Charge j<Delimiter>
Parameter
a (Measure) = ON/OFF
b (Measure Function) = DCV/DCA/OHM/TC/RTD/FREQ
c (Measure Range) = (DCV) 35 V/5 V/500 mV
(DCA) 100 mA/20 mA
(OHM) 50 kOHM/5 kOHM/500 OHM
(TC) K/E/J/T/R/B/S/N/L/U
(RTD) PT100/JPT100
(FREQ) 100 Hz/1000 Hz/10 kHz/CPM/CPH
d (Source) = ON/OFF
e (Source Function) = DCV/DCA/OHM/TC/RTD/PULSE
f (Source Range) = (DCV) 100 mV/1 V/10 V/30 V
(DCA) 20 mA/4-20 mA
(OHM) 500 OHM/5 kOHM/50 kOHM
(TC) K/E/J/T/R/B/S/N/L/U
(RTD) PT100/JPT100
(FREQ) 100 Hz/1000 Hz/10 kHz/50 kHz/CPM
g (Source Value)
h (Output for 24 V LOOP Measurement) = ON/OFF
i (Backlight) = ON/OFF
j (Charging) = OFF/ON
PU Normal SettingSets and queries display of PULSE (source)
○ × Command = PUm<Delimiter> → Answer = PUm <Delimiter>
Command = PU?<Delimiter>
→ Return = PUm <Delimiter>
Parameter m = 0: Frequency/1: Amplitude/2: Pulse Number
default Value m = 0 (Frequency)
This can only be set and queried when the source function is PULSE.
8.3 Detailed Description of Commands
