YOKOGAWA CA150 User Manual

8-12
IM CA150E
SD Normal SettingSets and queries the source values
○ × Command = SDm<Delimiter> → Answer = SDm <Delimiter>
Command = SD?<Delimiter>
→ Return = SDm <Delimiter>
Parameter
m = Source Values
100m V m = 0 to ±110.000 mV
1 V m = 0 to ±1.10000 V
10 V m = 0 to ±11.0000 V
30 V m = 0 to ±30.00 V
20 mA, 4-20 mA m = 0 to +22.000 mA
20 mA SINK m = 0 to -22.000 mA
500 Ω m = 0 to 550.00 Ω
5 kΩ m = 0 to 5.5000 kΩ
50 kΩ m = 0 to 55.000 kΩ
PT100 m = -200.0 to 850.0 °C
PT100 (ITPS-68) m = -200.0 to 650.0 °C
JPT100 m = -200.0 to 500.0 °C
K m = -200.0 to 1372.0 °C
E m = -200.0 to 1000.0 °C
J m = -200.0 to 1200.0 °C
T m = -200.0 to 400.0 °C
N m = -200.0 to 1300.0 °C
L m = -200.0 to 900.0 °C
U m = -200.0 to 400.0 °C
R m = 0 to 1768 °C
S m = 0 to 1768 °C
B m = 600 to 1820 °C
100 Hz (*1) m = 1.00 to 110.00 Hz
1000 Hz (*1) m = 90.0 to 1100.0 Hz
10 kHz (*1) m = 0.9 kHz to 11.0 kHz
50 kHz (*1) m = 9 kHz to 50 kHz
1000 CPM m = 1.0 to 1100.0 CPM
PULSE DCV (*2) m = 0 to 11.0000 V
PULSE Cycle (*3) m = 0 (cont), 1 to 60000 cycle
*1: When the PULSE source display setting is frequency, only (PU0) can
be set
*2: When the PULSE source display setting is amplitude, only (PU1) can
be set
*3: When the PULSE source display setting is pulse number, only (PU2)
can be set
SF Normal SettingSets and queries the source function
○ × Command = SFm<Delimiter> → Answer = SFm <Delimiter>
Command = SF?<Delimiter>
→ Return = SFm <Delimiter>
Parameter
m = 0: DCV/1: DCA/2: Ω/3: TC/4: RTD/5: Pulse
Set the PULSE source DCV and cycle of each parameter with the PU
command.
8.3 Detailed Description of Commands
