5-15

IM 701310-01E

Vertical and Horizontal Axes

App

Index

5.13 Correcting the Skew

Procedure

Press one of the CH1 to CH4 keys to select the channel.

Press the Next 1/2 soft key.

Use the rotary knob to set the screw correction value of the signal.

Explanation

Correcting the Skew

You can observe the signal by correcting the time offset (skew) between the CH1 to CH4nal by correcting the time offset (skew) between the CH1 to CH4al by correcting the time offset (skew) between the CH1 to CH4

signals. You can make corrections on each channel, CH1 to CH4. You can make corrections on each channel, CH1 to CH4.

Selectable range –80.00 to 80.00 ns (the default value is 0.00 ns)

Resolution 0.01 ns
