YOKOGAWA DL9000 Series User Manual

19-11
IM 701310-01E
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
19.11 General Specifications
Item Specifications
Standard operating conditions Ambient temperature: 23±5˚C
Ambient humidity: 55 �10%RH
Power supply voltage and frequency tolerance: Within 1% of rated value
Warm-up time At least 30 minutes
Storage conditions Temperature: –20to60˚C
Humidity: 20 to 80%RH (no condensation)
Operating conditions Temperature: 5to40˚C
Humidity: 20 to 80%RH (not using printer) (no condensation)
35 to 80%RH (using printer) (no condensation)
Recommended calibration
period
1 year
Storage altitude 3000 m or less
Operating altitude 2000 m or less
Rated supply voltage 100 to 120 VAC or 220 to 240 VAC (automatic switching)
Power supply voltage 90 to 132 VAC or 198 to 264 VAC
fluctuation tolerance
Rated supply frequency 50/60 Hz
Power supply frequency 48 to 63 Hz
fluctuation tolerance
Power supply fuse Internal (not replaceable)
Maximum power
consumption
300 VA
Withstand voltage (between 1.5 kVAC, one minute
power supply and case)
Insulation resistance
(between power supply and
case)
500 VDC, at least 10 M
W
External dimensions 350(W)
×
200(H)
×
178(D) mm (with printer cover packed away, excluding handle and other
projections)
Weight Approx. 6.5 kg (including printer)
Cooling method Forced air cooling, side ventilation
Installation orientation Horizontal (stand or handle may be used). Vertical and stacking prohibited.
Battery backup Setup data and clock are backed up with the internal lithium battery
Batterylife:Approx.
5years(atambienttemperature25˚C)
