Checking the Contents of the Package
Unpack the box and check the contents before operating the instrument. If some of the
contents are not correct or missing or if there is physical damage, contact the dealer from
whom you purchased them.
DL9000
Check that the product that you received is what you ordered. The table below contains
information about the available models, suffix codes, and options for your reference.
WARNING
Œx??
CAUTION
’ˆÓ
VIDEO OUT
(XGA)
PROBE POWER
( )
12 V DC
TRIG COMP OU T
TRIG IN
TRIG OUT
ETHERNET
100BASE-TX
ACT LINK
USB
GO/ NOGO
MAIN POWER
OFF ON
100 - 120/22 0 - 240 V AC
300 VA MAX 50/60 Hz
MODEL
NO.
SUFFIX
Made in Japan
MODEL
NO.
SUFFIX
Made in Japan
YOKOGAWA
MODEL SUFFIX Specifications
701307 DL9040 Digital Oscilloscope 4 channels, 5 GS/s 500 MHz, max.
2.5 MW/channel
701308 DL9040L Digital Oscilloscope 4 channels, 5 GS/s 500 MHz, max.
6.25 MW/channel
701310 DL9140 Digital Oscilloscope 4 channels, 5 GS/s 1 GHz, max. 2.5
MW/channel
701311 DL9140L Digital Oscilloscope 4 channels, 5 GS/s 1 GHz, max.
6.25 MW/channel
701312 DL9240 Digital Oscilloscope 4 channels, 10 GS/s 1.5 GHz, max.
2.5 MW/channel
701313 DL9240L Digital Oscilloscope 4 channels, 10 GS/s 1.5 GHz, max.
6.25 MW/channel
Power cord -D UL/CSA Standard power cord (Part No.: A1006WD)
[Maximum rated voltage: 125 V]
-F VDE Standard Power Cord (Part No.: A1009WD)
[Maximum rated voltage: 250 V]
-Q BS Standard Power Cord (Part No.: A1054WD)
[Maximum rated voltage: 250 V]
-R AS Standard Power Cord (Part No.: A1024WD)
[Maximum rated voltage: 250 V]
-H GB Standard Power Cord (Part No.: A1064WD)
[Maximum rated voltage: 250 V]
Help
language
-HE
-HJ
-HC
-HK
English
Japanese
Chinese
Korea
Options /B5
/P2
/C8
1
/C9
1
/C10
1
/C12
1
/G2
2
/G4
2
/F5
3
/F7
3
/F8
3
Built-in printer
Probe power supply
Built-in hard disk drive + Ethernet interface
Built-in hard disk drive + LXI compliant Ethernet interface
Ethernet interface
LXI compliant Ethernet interface
User-defined computation
Power supply analysis function
I
2
C + SPI + UART bus signal analysis function
CAN + LIN + SPI + UART bus signal analysis function
I
2
C + CAN + LIN + SPI + UART bus signal analysis function
1 /C8, /C9, /C10, and /C12 options cannot be specified simultaneously.
2 /G2 and /G4 options cannot be specified simultaneously. /G4 includes /G2.
3 /F5, /F7, and /F8 options cannot be specified simultaneously.
