Stopped
Running (acquisition in progress)
Pre (acquiring pre data)
Waiting for trigger
Post (acquiring post data)
Displayed record
length
Acquisition mode
Sample rate
Signal acquisition status
T/div. See section 4.2
Input channel status
Coupling
Scale
Probe attenuation rate
Trigger position
Computing/Reference
waveform status
Signal
acquisition count
Trigger position mark
Ground level mark
Vertical position mark
Trigger coupling, HF rejection,
hysteresis, and trigger delay
Trigger mode
Trigger source, Polarity
Trigger level
The LCD screen of this instrument may have a number of defective pixels.
