7.15 Setting X-Y Waveform Parameter GO/NO-GO

Determination Conditions

Procedure

Setting the GO/NO-GO Determination Mode

Press SHIFT+TRIG MODE/HOLD OFF (ACQ COUNT/ACTION).

Press these soft keys: Action on TRG > Zone/Param > Condition.

Selecting a GO/NO-GO Condition Number

Press the Select soft key.

Press the soft key that corresponds to the appropriate GO/NO-GO condition

number.
