19-14

IM 701310-01E

19.12 External Dimensions

Main unit

Units: mm

Unless otherwise specified, tolerances are �3% (�0.3 mm for dimensions less than

10 mm).

Rear View

177.815.5

92

20010

24.5 350 24.5
