Explanation
Select the number of windows for displaying the waveforms. The position for the
waveform of each channel varies depending on the display format.
Display Format
Single: 1 window, Dual: 2 windows, Triad: 3 windows, Quad: 4 windows
Waveform Mapping
• Auto
The waveforms are mapped in the order CH1, CH2, CH3, CH4, M1, M2, M3, and
M4, from the top of the divided screen. When the mapping reaches the bottom of the
divided screen it begins again from the top. Channels with displays that are turned
OFF are excluded.
• Manual
Specify where to map CH1 to CH4 and M1 to M4.
The number of points that can be
displayed within 8 div vertically depends on the display format (when the Main window
only is displayed).
The vertical resolution remains unchanged.
Single(
): 640 points, Dual( ): 320 points,
Triad(
): 208 points, Quad( ): 160 points
8.2 Changing the Display Format
