YOKOGAWA DL9000 Series User Manual

13-26
IM 701310-01E
Selecting the Color Mode
5.
Press the Color soft key.
6.
Press the soft key that corresponds to the desired color mode selection.
Selecting the Save Destination
7.
Press the File Path soft key.
8.
Use the rotary knob to select the storage medium and directory where the data
is to be saved and then press the Open soft key.
You can move to the parent directory by pressing the Up soft key.
9.
Press ESC.
Setting a File Name
10.
Set the file name according to steps 5 to 10 in section 13.4.
Executing the Save Operation
11.
When a screen that you want to save is displayed, press PRINT.
The screen image data is saved in the specified save destination.
13.8 Saving Screen Image Data
