4-9
IM 04P01B01-01E
Common Operations for Setting Functions and Setup Menu
4.3 Menu Structure, Settings, and List of Default Values
4
Setup Items in Setting Mode and Their Default Values
(Recorder version: 1.4x)
Items with an asterisk on the left are not displayed in the default condition. To display
these items, settings must be changed in Basic Setting mode.
Setup Item Pen/Dot Selectable Range or Selections Default Value
Range>CH - 01 to 06 01
Range>Mode - Volt/TC/RTD/1-5V/Scale/Delta/DI/SQRT/Skip Volt
Range>Mode>Range - 20mV/60mV/200mV/2V/6V/20V/50V/1-5V/
R/S/B/K/E/J/T/N/W/L/U/WRe/Pt/JPt/Level/Cont/
(Slections for /N1 and /N3 options)
2V
*Bias>CH - 01 to 06 01
*Bias>Bias - On/Off Off
*Bias>Bias - ±10% of the span of the measurable range or the
scaling span
-
Calibration (/CC1 option)
Calibration>CH - 01 to 06 01
Calibration>Calibration - On/Off Off
Calibration>datums - Within the range -
Calibration>revise - Within the range
(correction point + correction value for revise value)
-
Calibration>Decision - Yes/No Yes
Alarm>CH - 01 to 06 01
Alarm>Level - 1/2/3/4 1
Alarm>Alarm - On/Off Off
Alarm>Type - H/L/h/l/R/r (*/T/t) H
Alarm>Value - Depends on the alarm type. -
Alarm>Relay - On/Off Off
Alarm>RelayNo. - I01 to I06 I01
Unit>CH - 01 to 06 01
Unit>Unit - 6 characters or less Blank
Chart Pen Model 82 types (pen model) 20 mm/h
Dot Model 1 to 1500 mm/h (dot model) 20 mm/h
Clock - Date/Time -
Aux>Trend Dot Model Auto/Fix Auto
Aux>Zone>CH - 01 to 06 01
Aux>Zone>Left,Right - Within the recording span range (mm) Left: 0, Right: 100
*Aux>Partial>CH - 01 to 06 01
*Aux>Partial>Partial - On/Off Off
*Aux>Partial>Expand - 1 to 99% 50
*Aux>Partial>Boundary - Within the recording span range -
Aux>Printout>CH - 01 to 06 01
Aux>Printout>Trend Dot Model On/Off On
Aux>Printout>Periodic - On/Off On
Aux>Tag>CH - 01 to 06 01
Aux>Tag>Tag - 7 characters or less 1 to 6
Aux>Message>MessageNo. - 1 to 5 1
Aux>Message>(Message) - 16 characters or less Blank
Aux>Chart2 Pen Model 82 types (pen model) 20 mm/h
Dot Model 1 to 1500 mm/h (dot model) 20 mm/h
*Aux>Moving_AVE>CH Dot Model 01 to 06 01
*Aux>Moving_AVE>No.ofsamples Dot Model Off, 2 to 16 Off
*Aux>Filter>CH Pen Model 01 to 06 01
*Aux>Filter>Resp.Time Pen Model 2s/5s/10s Off
*Aux>AlmdelayT>CH - 01 to 06 01
*Aux>AlmdelayT>Duration - 0 to 3600s 10s
Aux>Brightness>Display - 1/2/3/4/5/6/7/8 4
Aux>Brightness>Light - 1/2/3/4 2
SD memory card (/EM1 option)
Aux>Datasave>Start,Stop - Funcmenu>Record>Batch FUNC menu
>Datareplay>Mode Dot Model Original/Current Original
>Saveparam>File - Up to 17 characters -
>Loadparam>File - Search text -
To Next Page
