IM 04P01B01-01E
4-10
4.3 Menu Structure, Settings, and List of Default Values
Setup Item Pen/Dot Selectable Range or Selections Default Value
Math (/M1 option)
Math>Formula>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Formula>Mode - On/Off Off
Math>Formula>f
.
- 120 characters or less 01
Math>Unit>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Unit>Unit - 6 characters or less Blank
Math>Constant>No. - K01 to K30 K01
Math>Alarm>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Alarm>Level - 1/2/3/4 1
Math>Alarm>Alarm - On/Off Off
Math>Alarm>Type - H/L (*/T/t) H
Math>Alarm>Value - –9999999 to 99999999 excluding the decimal -
Math>Alarm>Relay - On/Off Off
Math>Alarm>RelayNo. - I01 to I06 I01
Math>TLOG>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>TLOG>TimerNo. - Periodic/1/2 Periodic
Math>TLOG>SUMscale - Off, /s, /min, /h, /day Off
Math>Aux>Zone>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Aux>Zone>Left,Right - Within the recording span range (mm) Left: 0, Right: 100
*Math>Aux>Partial>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
*Math>Aux>Partial>Partial - On/Off Off
*Math>Aux>Partial>Expand - 1 to 99% 50
*Math>Aux>Partial>Bound - Within the recording span range -
Math>Aux>Printout>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Aux>Printout>Trend Dot Model On/Off On
Math>Aux>Printout>Periodic - On/Off On
Math>Aux>Tag>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Aux>Tag>Tag - 7 characters or less A to P
*Math>Aux>
Alm delay
T>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
*Math>Aux>
Alm delay
T>Duration - 0 to 3600s 10s
Batch (/BT1 option)
*Batch>BatchNo.
- 26 characters or less Blank
*Batch>LotNo.
- 0000-9999 or 000000-999999 0000 or 000000
*Batch>Detail>Start>Comment>LineNo.
- 1/2/3/4/5 1
*Batch>Detail>Start>Comment>(Comment)
- 32 characters or less Blank
*Batch>Detail>Start>Print>Batchname
- On/Off On
*Batch>Detail>Start>Print>Chartspeed
- On/Off On
*Batch>Detail>Start>Print>Clock
- On/Off On
*Batch>Detail>Start>Action>Feed
- 0 to 50 mm 0 mm
*Batch>Detail>End>Comment>LineNo.
- 1/2/3/4/5 1
*Batch>Detail>End>Comment>(Comment)
- 32 characters or less Blank
*Batch>Detail>End>Print>Batchname
- On/Off On
*Batch>Detail>End>Print>Chartspeed
- On/Off On
*Batch>Detail>End>Print>Clock
- On/Off On
*Batch>Detail>End>Action>Feed
- 0 to 50 mm 0 mm
*Batch>Detail>End>Action>Autoinc.
- On/Off On
*Batch>Detail>End>Action>POCoutput
Pen Model On/Off Off
*Batch>Detail>End>Action>POCspeed
Pen Model C.Speed/450 mm h C.Speed
*Batch>Detail>Start2...SameasStart
*Batch>Detail>End2...SameasEnd
*Batch>MSGformat>MessageNo.
- 1/2/3/4/5 1
*Batch>MSGformat>MessageNo.>(MSGformat)
- 35 characters or less H:M L16
