4-12
4.3 Menu Structure, Settings, and List of Default Values
Setup Item Pen/Dot Selectable Range or Selections Default Value
Language>Lang - English/Japanese/German/French English
Dateformat>Type - Y/M/D M/D/Y D/M/Y D.M.Y M.D.Y M.D.Y
Temperature>Temp - °C/°F °C
Personalize>Addfunction>Bias - Not/Use Not
Personalize>Addfunction>SQRTlow-cut - Not/Use Use
Personalize>Addfunction>1-5Vlow-cut - Not/Use Not
Personalize>Addfunction>Alarmdelay - Not/Use Not
Personalize>Addfunction>Calibration - Not/Use Use
Personalize>Timeprint>Alarm - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S,
YMD H:M:S
HH:MM
Personalize>Timeprint>Message - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S,
YMD H:M:S, None
HH:MM
Personalize>Timeprint>RCDOn - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S,
YMD H:M:S
HH:MM
Personalize>Timeprint>C.Speed - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S,
YMD H:M:S
HH:MM
Setting initialization
Initialize>Mode - Setup+Set/Set Setup+Set
Initialize>Mode>Areyousure? - No/Yes No
Remote (/R1 option)
Remote>RemoteNo. - 1/2/3/4/5 1
Remote>RemoteNo.>No. - Record On Off /Chart speed/Time adjust/
Math start stop (/M1)/Math reset (/M1)/
Manual print/Alarm ACK/Message1/Message2/
Message3/Message4/Message5/
Priority R_RCD (/BT1)/BatchCMT switch (/BT1)/
BatchCMT switch (/BT1)/Data save On/Off (/EM1)/
None
(/M1, /BT1, /EM1: option)
Record On/Off
Math (/M1 option)
Math>Timer(TLOG)>TimerNo. - 1/2 1
Math>Timer(TLOG)>Mode - Off/Relative/Absolute Absolute
Math>Timer(TLOG)>Interval(Relative) - 10 min to 24 h (1 min steps) 01:00
Math>Timer(TLOG)>Interval(Absolute) - 10min/12min/15min/20min/30min/1h/2h/3h/4h/6h/
8h/12h/24h
1h
Math>Timer(TLOG)>Ref.Time - Hour 0 to 23 (1 hour steps) 00:00
Math>Timer(TLOG)>Reset - On/Off On
Math>Timer(TLOG)>Print - On/Off On
Math>Color>Channel Dot Model 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Color>Color Dot Model Purple/Red/Green/Blue/Brown/Black Purple: 0A/0G
Red: 0B/0J
Green: 0C/0K
Blue: 0D/0M
Brown: 0E/0N
Black: 0F/0P
Math>Outputpen>Pen←CH Pen Model Pen: 1 to 4, Channel: 01 to 04/0A to 0J 1pen: 01, 2pen: 02,
3pen: 03, 4pen: 04,
Math>Print2>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Print2>Mode - AVE/MIX/SUM/MIN/MAX/INST AVE
Math>Print2>SUMscale - Off, /s, /min, /h, /day Off
Math>Bargraph>CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
Math>Bargraph>Graph - Normal/Center Normal
Math>Errordata>Error - +Over/–Over +Over
Math>Errordata>Over - Skip/Limit Skip
RS-422/485 (/C3 option)
RS-422/485>Address - 1 to 32 1
RS-422/485>Baudrate - 1200/2400/4800/9600/19200/38400 9600
RS-422/485>Datalength - 7/8 8
RS-422/485>parity - Odd/Even/None Even
RS-422/485>Protocol - NORMAL/MODBUS NORMAL
