5.1 Setting the Input Range
Description
• Selectable Range of Input Range, Span Left, and Span Right
The input range, span left, and span right can be set in the range shown below. Span
left and span right cannot be set to the same value.
DC voltage (Volt)
Range Type Selectable Span Range
20 mV –20.00 to 20.00 mV
60 mV –60.00 to 60.00 mV
200 mV –200.0 to 200.0 mV
2 V –2.000 to 2.000 V
6 V –6.000 to 6.000 V
20 V –20.00 to 20.00 V
50 V –50.00 to 50.00 V
Thermocouple (TC)
Range Type Selectable Span Range (°C) Selectable Span Range (°F)
R 0.0 to 1760.0°C 32 to 3200°F
S 0.0 to 1760.0°C 32 to 3200°F
B 0.0 to 1820.0°C 32 to 3308°F
K –200.0 to 1370.0°C –328 to 2498°F
E –200.0 to 800.0°C –328.0 to 1472.0°F
J –200.0 to 1100.0°C –328.0 to 2012.0°F
T –200.0 to 400.0°C –328.0 to 752.0°F
N 0.0 to 1300.0°C 32 to 2372°F
W 0.0 to 2315.0°C 32 to 4199°F
L –200.0 to 900.0°C –328.0 to 1652.0°F
U –200.0 to 400.0°C –328.0 to 752.0°F
WRe 0.0 to 2400.0°C 32 to 4352°F
RTD
Range Type Selectable Span Range (°C) Selectable Span Range (°F)
PT (Pt100) –200.0 to 600.0°C –328.0 to 1112.0°F
JPT (JPt100) –200.0 to 550.0°C –328.0 to 1022.0°F
RTD
Range Type Selectable Span Range (°C) Selectable Span Range (°F)
PT (Pt100) –200.0 to 600.0°C –328.0 to 1112.0°F
JPT (JPt100) –200.0 to 550.0°C –328.0 to 1022.0°F
/N1 Option /N3 Option
Selections Input Type Selections Input Type Note
Cu1 Cu10 (GE) PR PR40-20 Thermo
couple
Cu2 Cu10 (L&N) PLATI PLATINEL
Cu3 Cu10 (WEED) NiMo NiNiMo
Cu4 Cu10 (BAILEY) W/WRe W/WRe26
Cu5 Cu10: a = 0.00392 at 20°C N2 Type N (AWG14)
Cu6 Cu10: a = 0.00393 at 20°C Kp Kp vs Au7Fe
Cu25 Cu25*: a = 0.00425 at 0°C Pt4 Pt25 RTD
Pt3 Pt50
Ni1 Ni100 (SAMA)
Ni2 Ni100 (DIN)
Ni3 Ni120
J263 J263*B
Cu8 Cu53
Cu9 Cu100: a = 0.00425 at 0°C
