Display functions
Item Description Reference
Section
Display brightness Use Aux > Brightness > Display in Setting mode to set the display brightness. 6.11
Bar graph display mode Use Bar graph in Basic Setting mode to set the bar graph display mode. 7.9
Display type Assigns the display type on the data display setup Screen No. Chapter 8
Date format Same as the Date format in “Recording functions.” 7.19
Other functions
Item Description Reference
Section
Key lock • Target keys and password 7.10
Use Keylock in Basic Setting mode to set the keys to be key-locked and the
password.
• Enable the key lock 3.13
Use Func > Keylock in Operation mode and select Use or Not.
Customized menu • Selecting the FUNC key display menu 7.20
Use Select menu > Function in Basic Setting mode to select the menus to be
displayed.
• Selecting the displayed menu of Setting mode 7.21
Use Select menu > Set mode in Basic Setting mode to select the menus to be
displayed.
• Executing the customize menu 7.22
Use Cust. menu in Basic Setting mode to set whether to use the customized menu.
If Use is selected, only the menus set to ON in the menu selection are displayed, and
Basic Setting mode is locked.
If Not is selected, all menus are displayed, and the Basic Setting mode lock is
released.
Language Use Language in Basic Setting mode to set the display and printout language. 7.14
Internal light brightness Use Aux > Brightness > Light in Setting mode to set the internal light brightness. 6.11
Computation function (/M1 option)
Item Description Reference
Section
Computing equation and recording span
Use Math > Formula in Setting mode to set the computing equation and recording
span for each channel.
9.2
TLOG computation If TLOG computation is selected, use Math > Timer in Basic Setting mode to set the
timer operation
9.12
Use Math > TLOG > Timer No. in Setting mode to set the timer used on each
computation channel.
9.6
Unit Use Math > Unit in Setting mode to set the unit for each channel. 9.3
Constants Use Math > Constant in Setting mode to define constants to be used in the computing
equations.
9.4
Alarms Use Math > Alarm in Setting mode to set the alarm for each channel. 9.5
• Delay high limit alarm/delay low limit alarm
• Alarm type 7.15
Use Personalize > Add function > Alarm delay in Basic Mode and select Use or
Not (common with measurement channels).
If Use is selected, delay high limit alarm and delay low limit alarm become selectable
under Math > Alarm > Type in Setting mode. If Not is selected, alarm delay cannot
be selected.
• Alarm delay time 9.11
Use Math > Aux > Alm delay T in Setting mode to set the alarm delay time.
Record by setting recording zone
Use Math > Aux > Zone in Setting mode to set the recording zone for each channel. 9.7
Partial expanded recording Use Partial in Basic Setting mode and select Use or Not. 7.13
If Use is selected, set the display mode using Math > Aux > Partial in Setting mode. 9.8
If Not is selected, the Math > Aux > Partial item does not appear.
Change the recording color (dot model)
Use Color in Basic Setting mode to set the recording color of each computation
channel.
9.13
1.10 Function Setup Guide
