YOKOGAWA UM33A User Manual

4-3
IM 05P03D21-01EN
Basic Operation
4
DisplayShownattheEnd(theLowestLevel)oftheParameterSettingDisplay
As shown in the figure below, the END Display is shown to indicate the end of the Menu
Display and Parameter Setting Display. There are no setting items.
END is displayed.
The scrolling guide of END is displayed.
BasicKeyOperationSequence
● TomovetotheSetupParameterSettingDisplay
Hold down the PARA key and the Left arrow key simultaneously for 3 seconds.
Hold down the keys
for 3 seconds.
+
● TomovetotheOperationParameterSettingDisplay
Hold down the PARA key for 3 seconds.
Hold down the key
for 3 seconds.
● TomovetotheOperationDisplay
Press the DISP key once.
4.1OverviewofDisplaySwitchandOperationKeys
