8
1.6.4.2 F-Series – FISP Cell-Free Sampling Probe
The F-Series probes are used for autoclaveable glass vessels which have a 12 mm or 19 mm headplate port. Additionally,
the F-series probes come in a variety of lengths to fit various vessel sizes and depths. Figure 1-13 details the F-Series
sampling probe. The standard configuration is provided with a PEEK female Luer connector, which is designed for use with
the Multi-Channel Online Monitor (Figure 1-7).
Figure 1-7
Beveled Washer/O-Ring Kit for F-Series Probe
Beveled Washer facing O-Ring
Female Luer Adapter to 10-32, PEEK, tan
