E Series Service Manual
9650-1450-01 Rev. D 1-29
17.0 SpO
2
Monitor Test for SpO
2
Option
Tools Needed:
• Masimo
ï€
Reusable Sensor.
• Masimo

Patient Cable
• Fluke Index Series 2 SpO
2
Simulator.
Test Setup:
1. Connect the universal cable to the MFC test plug.
2. DO NOT connect the ECG cable to the simulator.
3. Connect the Masimo

Patient Cable and attach the Masimo

sensor to the patient cable.
4. Connect the Masimo

sensor to the finger simulation post.
5. Place a fully charged battery into the battery well or connect to ac power (dc power, if equipped).
6. Ensure that the SpO
2
Simulator is off.
Do this... Verify that... Pass/Fail
17.1 Turn the selector switch to MONITOR.
(For AED units, turn the selector switch to ON
and select Manual mode.)
The SpO
2
saturation percentage appears as a dashed line on the monitor.
o o
17.2 Wait ten seconds.
Turn on the SpO
2
simulator. Press the SIM
softkey on the Index SpO
2
Simulator, then press
the MAN softkey.
The unit displays the SpO
2
PULSE SEARCH message.
o o
17.3 Press the 02+ or 02- softkey of the simulator
until the SpO
2
output is at 98%.
The SpO
2
reading of 98 +/- 1% appears on the E Series monitor.
Note: You may need to wait up to 2 minutes for the information to appear on
the ZOLL display.
o o
17.4 Using the Index SpO
2
Simulator, press the
BPM+ or BPM- softkey until the heart rate is
230 BPM.
The SpO
2
simulator screen displays an SpO
2
rate of 230 BPM.
Note that you may need to wait up to 2 minutes for the information to appear on
the ZOLL display.
The E Series monitor displays an SpO
2
saturation of 96-100%.
The E Series monitor displays a heart
rate of 226-234 BPM.
o o
