ZOLL E Series Service Manual

E Series Service Manual
1-30 9650-1450-01 Rev. D
17.5 Using the Index SpO
2
Simulator, press the
BPM- softkey until the heart rate is 50 BPM
The SpO
2
simulator screen displays an SpO
2
saturation of 96-100%.
The E Series monitor displays a heart rate of 46-54 BPM.
o o
o o
17.6 Using the Index SpO
2
Simulator, press the 02+
softkey until the SpO
2
output is at 72%.
The SpO
2
simulator screen displays an SpO
2
saturation of 70-74%.
The E Series monitor displays a heart rate of 46-54 BPM.
o o
o o
17.7 Press Wave 2 softkey.
Select the SpO
2
waveform.
Plethysmographic waveform appears on the ZOLL display.
o o
17.8 Press RECORDER. The plethysmographic waveform prints on the strip chart paper.
o o
17.9 Using the Index SpO
2
Simulator, press the
BPM- softkey until the heart rate is at 230 BPM.
The SpO
2
simulator screen displays an SpO
2
saturation rate of 70-74%.
The E Series monitor displays a heart rate in the heart position of 
226-234 BPM.
o o
17.10
Remove the Masimo

patient cable.
Record your results on the Maintenance Tests Checklist.
Do this... Verify that... Pass/Fail

ZOLL E Series Specifications

General

Display Type	Color LCD
ECG Monitoring	Yes
Pacing	Yes
Pacing Rate	30-180 ppm
SpO2	Optional
NIBP	Optional
EtCO2	Optional
Printer	Integrated
Data Management	Yes
CPR Feedback	Yes
IP Rating	IP55
Pacing Output	0 - 140 mA
Battery Type	Rechargeable lithium ion
Battery Life	4 hours
Energy Selection	1-360 Joules
Display Size	6.5 inches
