3D Systems ProX 800 User Manual

3D Systems, Inc.
62
Remove Print Platform Without Ooad Cart
1. Navigate to Tools > Elevator/Leveler Settings and press
Move to Ooad. This will move the recoater down 2” and
the print pad up. If you have a material ooad cart, skip to
the section, “Remove Build Platform With Ooad Cart” on
the next page.
NOTE: the Move to Ooad settings are already set in
the software. If any adjustments need to be made,
follow the steps in “Setting the Ooad Position” on
page 54.
NOTE: Always wear nitrile gloves when removing the
print pad. If any material gets on your skin, wash
immediately with soap and water.
NOTE: Do not clean build platform while over the vat,
as debris from paper towels or cleaning agents will
contaminate the resin below.
2. You may see a popup asking, “Is platform in lowered
position?” Click “yes.”
3. Being in this position near the timing plate, the latches for
the print pad will be disengaged.
4. Allow part(s) to drain over vat for 30 minutes.
5. Wearing nitrile gloves, remove the print platform with the
help of another person, each person grabbing the platform
on either side. Place platform on workbench or other at
surface you have set aside for post-processing.
6. To remove build parts from the platform, follow the steps
outlined in the following section.
ProX 800
ProX 800
Ooad position must
reach this point
Timing Plate
Ooad position to disengage the print pad lock
