3D Systems ProX 800 User Manual

3D Systems, Inc.
51
MATERIAL DELIVERY MODULE TEMPERATURE CONTROL
The ProX 800 offers oine and online heating. When the power cord from the machine is connected to the MDM, the
system has online heating. When the power from a wall outlet is connected, the system has oine heating. The MDM can be
heated either outside the system enclosure, via the stand-by mode, or inside the enclosure. To prepare for printing, heat the
material to its operating temperature of 28 °C (+/- 3 °C). Typical time for heating is two to three hours, but cold material can
take considerably longer.
NOTE: We recommend only heating the material up to 24 hours prior to use. Constantly heating the material
when not in use will prematurely age the material.
AUTO MATERIAL REFILL SYSTEM
The auto material rell system is located on the MDM. This system adds material to the MDM from the material container
located in the rell slot. If the material level is too low, the auto material rell system will display the message, “Material
Autoll in Progress,” and will empty all of the material from the rell container. The print job starts after the material reaches
the correct level in the reservoir. If the material rell container is empty, the system will alert the user to replace it with a full
container. For more information see “Installing Material Containers” on page 52 and “Material Container Removal” on page
53.
MDM REMOVAL
Refer to the illustrations in the section, “Material Delivery Module (MDM) Installation” on page 49.
HOT SURFACE: The area underneath the MDM is hot—Do not reach underneath!
To move the MDM out of the machine, follow these steps:
1. From the Elevator/Leveler Settings Screen, press the Drain MDM button to transfer material to the leveling reservoir
which will reduce the risk of overow when rolling the MDM out of the printer.
2. Move the elevator to its lowest position so the forks can remain with the MDM. The elevator will stop when it reaches this
position.
• From the Print Applicator Screen, press Move to Home to home the print applicator.
• From the Elevator/Leveler Settings Screen, press Move to Home to home the elevator.
• In the Elevator/Leveler Settings Screen, press the Edit icon for Move Distance and set the value to “-10.”
• Press the Move Distance button.
3. Open the print chamber door.
4. Turn off the heater power switch and disconnect the AC power cord from the socket.
5. Disconnect the I/O Connection Cord and the Serial Connection Cable.
6. Remove the print applicator from the print chamber and place the applicator in the storage area on the MDM. See the
section “Print Applicator Installation and Removal” on page 48.
7. Place the MDM lid onto the MDM.
8. Unlock the caster wheels.
9. Pull up the black locking pin and turn to lock it in the “up” position. The cart may now be removed from the machine.
10. Make sure that all cables are out of the way of the MDM before you remove it from the machine.
11. Carefully roll the MDM out of the machine and close the print chamber door.
Move the MDM very slowly. Sudden starts and stops can create waves in the material and result in material
spills, even with the MDM lid in place. Continuous slow movement is important.
11. Level material by navigating to the Tools > Elevator/Leveler screen and pressing Level MDM.
12. Install the print applicator following the instructions in the section “Print Applicator Installation and Removal” on page
48.
