Naming a Unit
www.3ware.com 141
Naming a Unit
Units attached to 9000-series controllers can be given unique names to more
easily identify them. A unit can be assigned a name when it is created. The
name can also be added or changed later.
To name or rename a unit through 3DM
1 Make sure the appropriate controller is selected in the drop-down list at
the right of the menu bar.
2 Choose
Management > Controller Settings from the menu bar in 3DM.
3In the
Unit Names section of the Controller Settings Page, locate the unit
for which you want to change the name.
4 In the text box, enter or type over the name shown.
A name can be up to 21 characters, and can include dashes and
underscores.
5 Click the
Save Names button.
Note: If you want to cancel your change before saving it, click
the
Reset Names button.
To name or rename a unit through 3BM
1 At the main 3BM screen, select the unit by highlighting it and pressing
Enter.
An asterisk appears in the left-most column to indicate that it is selected.
2
Tab to the Maintain Unit button and press Enter.
3 On the pop-up menu, select
Configure and press Enter.
On the Configure Disk Array screen, the
Array Name field is already
selected.
4 Press
Enter to open a text box.
5 Type a name for the unit and press
Enter.
6
Tab to the OK button and press Enter to select it.
You return to the main 3BM screen.
7 When you are finished making changes, press
F8 to save them and exit
3BM.
