3ware BIOS Manager 2
(3BM 2)
This section describes the basics of using 3ware BIOS Manager 2 (3BM 2),
one of the tools you can use to configure and maintain the units connected to
your 3ware 9550SX or 9590SE RAID controller.
For information about doing particular tasks in 3BM, refer to the later sections
in this guide.
This section is organized into the following topics:
• “Starting 3BM 2” on page 55
• “Exiting the 3BM Configuration Utility” on page 57
• “Working in the 3BM Screens” on page 58
• “Displaying Controller Information” on page 63
• “Getting Help While Using 3BM” on page 63
Starting 3BM 2
You access 3BM during the start-up process for your computer.
To start 3BM
1 Power up or reboot your system.
2 While the system is starting, watch for a screen similar to Figure 24.
Figure 24. 3ware BIOS Screen
3 Press Alt-3 immediately to bring up the 3ware BIOS Manager (3BM).
----Press <Alt-3> to access 3ware BIOS Manager ----
3ware ATA RAID Controller: 9590SE-12
BIOS: BE9X X.XX.XX.XXX Firmware: FE9X X.XX.XX.XXX
BBU Status: Not Present
Number of online units: 1, available drives: 0, hot spare: 0, offline units:0
Exportable Units:
3drive 64K RAID5 558.77GB (PrimaryRAID5)
Port0 Maxtor 7B300S0 279.48 GB
Port1 Maxtor 7B300S0 279.48 GB
Port2 Maxtor 7B300S0 279.48 GB
To Next Page
